IR Infrared Flame Sensor Module

Description

The IR Infrared Flame Sensor Module is designed to detect the presence of flames or fire using infrared radiation. It is commonly used in fire detection systems, safety applications, and projects where the presence of flames needs to be detected for triggering specific actions. This module integrates an infrared sensor that detects the infrared radiation emitted by flames, enabling it to identify potential fire sources and activate alarms or safety measures.

It can detect flame or wavelength in the range of 760 nm ~ 1100 nm light source, lighter test flame distance is 80cm, the greater the flame, the farther the test distance,the detection angle 60 degrees or so, especially sensitive to flame spectrum, sensitivity adjustable (blue digital potentiometer adjustment in the figure) comparator output, signal clean, good waveform, strong driving ability, more than 15mA with adjustable precision potentiometer Adjustment sensitivity

Specifications:
Sensor Type: Infrared (IR) flame detection sensor
Detection Method: Detects infrared radiation emitted by flames
Operating Voltage: Typically 3.3V or 5V (module variant dependent)
Output Signal: Typically provides a digital output (HIGH/LOW) indicating flame presence
Sensitivity Adjustment: Some modules may offer sensitivity adjustment
Form Factor: Compact module with signal pins for easy integration
Dimensions:3.2cm x 1.4cm

Applications:
Fire detection systems: The module can be used in fire detection systems to quickly and accurately detect the presence of flames, allowing for early warning and prevention of fires.
Industrial automation: The module can be used in industrial automation systems to detect flames in machinery, ensuring safe and reliable operation.
Robotics: The module can be used in robotics applications to detect flames or light sources and enable the robot to react appropriately.
Security systems: The module can be used in security systems to detect flames or light sources and trigger alarms or other responses.
Home automation: The module can be used in home automation systems to detect flames or light sources and trigger automated responses, such as turning off appliances or turning on sprinkler systems.
Environmental monitoring: The module can be used in environmental monitoring systems to detect wildfires or other natural disasters, enabling early response and mitigation.

Package Includes:
1 x IR Infrared Flame Sensor Module
